| Frame |
Spark RC HMF Carbon Gen5, adjustable head angle and fork lock, Syncros Octopus cable integration system Gen2, BSA BB, UDH interface, 12x148mm with 55mm chainline
|
| Fork |
RockShox SID 3P Air, Rush RL 3P Damper, 15x110mm Maxle Stealth, tapered steerer, Reb. Adj., Lockout
|
| Travel |
Front: 120 mm, Rear: 120 mm
|
| Rear Shock |
RockShox SIDLuxe Select+, 3P Lockout-Pedal-Descend, Solo Air, Reb. Adj., Lockout, bearing hardware 20x8mm, 190X45mm
|
| Remote System |
SCOTT TwinLoc Technology, Suspension & Dropper Remote, 3 Suspension modes
|
| Headset |
Syncros - Acros Angle adjust +-0.5°, fork lock & cable routing Gen2 system, IS52
|
| Rear Derailleur |
Shimano Deore RD-M7200 12-speed
|
| Shifters |
Shimano Deore SL-M6200
|
| Brakes |
Shimano BR-MT600 2-Piston
|
| Crankset |
Shimano FC-MT520, 34T
|
| Front Disc Rotor |
Shimano RT-CL300, 180mm
|
| Chainguide |
Spark RC Gen5 chainguide
|
| Rear Disc Rotor |
Shimano RT-CL300, 160mm
|
| BB-Set |
Shimano BB-MT501 BSA
|
| Handlebar |
Syncros HB-M100-AL2, Alloy 6061 DB, Flat, 7°, 740mm, Syncros XC lock-on grips
|
| H'stem |
Syncros XC ST-M100-AL2, -6°, 31.6mm
|
| Seatpost |
Syncros dropper post SP-M302-AL2, 31.6mm
|
| Seat |
Syncros Celista Cut Out
|
| Front Hub |
Formula CL-811, 15x110mm
|
| Rear Hub |
Formula FCL-548M, 148x12mm, Micro Spline
|
| Chain |
Shimano CN-M6100
|
| Cassette |
Shimano Deore CS-M6200, 10-51T
|
| Spokes |
Stainless Black
|
| Front Rim |
Alex Rims X-30SE 32H, Tubeless ready
|
| Rear Rim |
Alex Rims X-30SE 32H, Tubeless ready
|
| Extras |
Syncros Tool
|
| Approx weight in KG |
12.9 Tubless
|
| Approx weight in LBS |
28.44 Tubless
|
| Grips |
Syncros XC Lock-On, ready for Tubeless plug Kit Storage
|
| Front Tire |
Maxxis Aspen 29x2.4", 120TPI Foldable Bead, tubeless ready, EXO
|
| Rear Tire |
Maxxis Aspen 29x2.4", 120TPI Foldable Bead, tubeless ready, EXO
|
